GENERAL
----------
Frequency range: 26.960 - 27.400 MHz
Number of channels: 40 FM/AM
Frequency control: PLL phase-locked loop
Operating temperature: -10°C - 55°C
Power supply: DC 13.8 V ±15%
Dimensions (LxWxH): 180 x 140 x 35 mm
Weight: 0.850 kg
----------
RECEIVER
----------
Receiving system: double conversion superheterodyne
Intermediate frequencies: 10.695 MHz and 455 kHz
Sensitivity: <1µV for 20 dB SINAD
Audio output power: min. 2.0 W at 8 Ohms
Audio distortion: < 3% at 1 KHz
Current consumption on reception: 200 mA
----------
TRANSMITTER
----------
Output power: DC 4 W at 13.8 V
Modulation: AM: 85% - 95% FM: 1.8 KHz ±0.2 KHz
Maximum current consumption: 1100 mA (without modulation)
